ZF500 Series Axial Flow Fan - Efficient Ventilation Solution

Model: ZFA500-3S-01 to ZFA500-6S-02
Blade Diameter: 500mm
Voltage: 220V or 380V
Frequency: 50Hz
Speed: 855-1450rpm
Power: 0.1-0.37kW
Airflow: 4600-8100m³/h
Noise: 58-63dB(A)
Materials: Aluminum/plastic blades; steel guide plates; aluminum/steel motor housing

Model:
ZF500 Series Axial Flow Fan
Brand:
SHINE
Code:
20221135


Availability:



Inquiry

Product Description

Durable & Corrosion-Resistant Construction

The ZF500 Series features rust-proof aluminum or plastic blades, ensuring long-term durability in harsh environments. Cold-rolled steel guide plates enhance airflow efficiency, while motor housings and end caps are available in aluminum or steel—both powder-coated with pure polyester outdoor paint for superior corrosion resistance. Anodization options for blades and housings further extend service life.

Versatile Performance

With a 500mm blade diameter and variable speeds (855-1450rpm), these fans deliver 4600-8100m³/h airflow, suitable for diverse ventilation needs. The 220V/380V voltage options and multiple models (3S/3D/4S/6S) provide flexibility for different applications, from small workshops to commercial buildings.

Efficient & Low-Noise Operation

Equipped with high-quality motors and precision-balanced blades, the ZF500 Series operates at 58-63dB(A), ensuring quiet performance. The axial flow design minimizes energy consumption, making it an eco-friendly choice. Easy installation and maintenance, combined with robust construction, ensure reliable operation in various settings..

153509285058 571534226692215 4581534226723764 3401534226728572

9601534226833720

Specification Table

Model	Blade Diameter (mm)	Voltage (V)	Frequency (Hz)	Speed (rpm)	Power (kW)	Current (A)	Airflow (m³/h)	Noise (dB(A))
ZFA500-3S-01	500	380	50	900	0.1	0.45	5100	59
ZFA500-3D-01	500	220	50	855	0.1	0.84	4600	58
ZFA500-4S-01	500	380	50	930	0.18	0.95	5800	60
ZFA500-6S-01	500	380	50	1450	0.37	1.39	8100	63
ZFA500-6S-02	500	380	50	937	0.18	0.95	5650	60

Application

Industrial & Commercial Ventilation

The ZF500 Series is widely used in small-to-medium industrial workshops, warehouses, and commercial buildings. Its compact size and efficient airflow (4600-8100m³/h) make it ideal for ventilating workshops, removing fumes and dust, and maintaining air quality. In commercial settings like retail stores and offices, the low-noise operation (58-63dB(A)) ensures a comfortable environment.

The corrosion-resistant design and durable materials make it suitable for outdoor applications, such as rooftop ventilation or cooling systems for data centers. With multiple voltage and speed options, it can be customized to meet specific needs, from low-power residential ventilation to high-performance industrial exhaust systems.

Note

The above are representative specifications for reference only. Customized designs are available per user requirements. For any changes, please contact our technical department for the latest information.
