CYYZ11 Nissan Series Pressure Sensor | 0.8-4.5MPa High-Precision Transmitter

The CYYZ11 is tailored for Nissan series models: 5±0.25VDC supply, ≤10mA current, 0.5-4.5VDC customizable output (≤2.0ms response). It covers 0.8-4.5MPa pressure, offers ±1.0% accuracy (25℃), 1M cycle life, and operates at -30~125℃ with silicone-compatible media.

Model:
CYYZ-11 High-Precision Pressure
Brand:
SHINE
Code:
20221171


Availability:



Inquiry

Product Description

CYYZ11: Specialized Pressure Sensor for Nissan Series Vehicles

The CYYZ11 is engineered for Nissan series models, with core specs optimized for Nissan’s automotive systems:

Category	Item	Specification
Electrical	Supply Voltage	5±0.25VDC (VCC=5.000VDC)
	Output Voltage	0.5-4.5VDC (customizable 0.10-4.90VDC)
Performance	Pressure Range	0.8-4.5MPa (relative)
	Accuracy (25℃)	±1.0%VCC
Environment	Operating Temp	-30~125℃

In Nissan vehicle applications, it monitors transmission oil pressure, brake system pressure, and power steering pressure—its 0.8-4.5MPa range aligns with Nissan’s hydraulic system parameters, while ≤2.0ms response enables real-time control. 16VDC overvoltage protection guards against on-board electrical fluctuations.

It also suits light industrial scenarios (e.g., small-scale hydraulic equipment) paired with Nissan auxiliary systems. The 2.0×Fs burst pressure ensures safety under extreme loads, and -30~125℃ operating temp adapts to engine bay heat and cold-weather conditions. Silicone-compatible media covers Nissan’s standard hydraulic oil.

CYYZ11: Nissan Series-Grade Quality & Reliability

The CYYZ11 meets Nissan’s automotive quality standards, with strict controls:

Component Durability: Its silicon piezoresistive core passes 1,000-hour high-temperature aging, maintaining ±1.0% accuracy (25℃); full-temp error (-40~125℃) ≤±3.0%VCC matches Nissan’s extreme-environment requirements.
Rigorous Testing: It withstands 1M pressure cycles (matching Nissan’s system durability needs), 16VDC overvoltage, and reverse voltage shorts. Storage stability (-40~140℃) resists long-term storage harshness.
Precision Production: Automated assembly + laser calibration minimize drift (≤±0.1%FS/100℃), ensuring compatibility with Nissan’s on-board electronics. All units undergo 24-hour high-low temp cycling before delivery.
Traceability: 2-year warranty with SPC reports; production batch/calibration data is fully traceable, meeting Nissan’s supply chain audit standards.

Application

The CYYZ11 serves Nissan series vehicle hydraulic systems (transmission oil, brake, steering pressure), plus Nissan auxiliary industrial equipment (small hydraulic pump monitoring). It works with Nissan’s standard silicone-compatible hydraulic oil, operating across -30~125℃ environments to fit diverse driving and working scenarios.
